Ruger RSM Rebarrel

Shawn.54

AH fanatic
Joined
Jul 25, 2016
Messages
706
Reaction score
727
Location
USA western pa
Media
10
Member of
NRA
The actions mentioned in the RUM line would need the least amount of work but the bolt face will need a little work because the RUM cartridge has a rebated rim it is the same as all the belted mags so a little work would be needed. Standard mag bolt face is .535 404 Jeffery is .545. The 404 will probably slide into the .535 bolt face because they build in a little play but to keep the same play in 404 you need to make it a bit bigger.
Shawn
I’m in the last stages of a 404 Jeffery on a standard 98. Should have it shooting by mid February and doing all the work myself except PAC NOR barrel.


geoff rath

AH enthusiast
Joined
Apr 4, 2017
Messages
405
Reaction score
330
case diameter is the big bugbear on that one, unfortunately...:cry:


ActionBob

AH legend
Joined
Dec 12, 2011
Messages
3,810
Reaction score
6,126
Location
Central Minnesota
Media
96
Hunting reports
Africa
4
Mex/S.Amer
1
Member of
NRA life, DSC, SCI
Hunted
Minnesota, Texas, South Africa, Zimbabwe, Mozambique, British Columbia, Argentina, Kansas, Macedonia, Austria
Instead of a Ruger RSM in 375 H&H, would it make more sense or at least be a little easier to rebore a Ruger RSM in .416 Rigby to 404 (which is really .423)?
I think the chamber would be an issue.


ActionBob

AH legend
Joined
Dec 12, 2011
Messages
3,810
Reaction score
6,126
Location
Central Minnesota
Media
96
Hunting reports
Africa
4
Mex/S.Amer
1
Member of
NRA life, DSC, SCI
Hunted
Minnesota, Texas, South Africa, Zimbabwe, Mozambique, British Columbia, Argentina, Kansas, Macedonia, Austria

sandman0921

Gold supporter
AH enthusiast
Joined
Dec 13, 2014
Messages
420
Reaction score
574
Location
Tennessee, USA
Media
2
Articles
11
Hunting reports
USA/Canada
1
Member of
SCI (Life), RMEF (Life), DU, NWTF, NRA (Patron Life), GOA, DSC (Life), WSF (Life), B&C Club (Sponsor Associate Member), USSA (Associate Member)
Hunted
USA (GA, TN, AR, TX, FL, UT, NM, WY, MT, AK, IL, MO, IA); Canada (NWT, BC); Africa (Tanzania)
Patience and persistence is key to finding a M70 in 300 RUM

That is for sure. They are very difficult to find. Occasionally see one from time to time on various firearms classifieds, but overall a pretty rare bird....

Before I decided to have Wayne build an AHR custom 404 Jeffery, I searched for weeks trying to find a Winchester M70 in 300 RUM, but to no avail...Ultimately I went with Wayne's DGR utilizing a CZ550 Magnum Action and I couldn't be happier....


AZDAVE

AH elite
Joined
Jul 26, 2013
Messages
1,819
Reaction score
2,474
Media
166
Hunting reports
Africa
3
Hunted
South Africa, Alaska,lower 48
I had pac nor rebarrel the 375 RMS. the problem is as mentioned here the 1/4 rib is machined into the barrel, and the 375 and larger RMS's have a under-rib that you have to fabricate to work with the additional recoil lug system built in the stock. (If you remove the action from the stock you will see difference) You would same money and time to either have Pac-nor or barrel maker of your choice rebarrel a WIN 70. Or just buy a CZ from the factory set up from the start in 404 Jeff. You can make a RMS work but is not an easy project.


sierraone

Silver supporter
AH legend
Joined
Oct 14, 2013
Messages
3,742
Reaction score
3,502
Media
91
Articles
1
Hunting reports
Africa
2
Member of
Dallas Safari Club, Safari Club Int.
Hunted
USA, RSA, Northwest and Limpopo Provinces
I had pac nor rebarrel the 375 RMS. the problem is as mentioned here the 1/4 rib is machined into the barrel, and the 375 and larger RMS's have a under-rib that you have to fabricate to work with the additional recoil lug system built in the stock. (If you remove the action from the stock you will see difference) You would same money and time to either have Pac-nor or barrel maker of your choice rebarrel a WIN 70. Or just buy a CZ from the factory set up from the start in 404 Jeff. You can make a RMS work but is not an easy project.
Hi Dave, I hope your family medical issues are just history now! I could not be happier with the RMS 404 project you started and I acquired, then had a smith finish it to my desires! It will see Africa in July and with a little luck will be draw blood for the first time!


ChrisG

AH elite
Joined
Jan 6, 2015
Messages
1,024
Reaction score
1,132
Location
Adirondack Park, NY, USA
Media
43
Articles
1
Hunting reports
USA/Canada
3
Member of
NAHC, NRA, Rocky Mtn. Elk Foundation.
Hunted
USA, Canada
I would think it would be possible have the rifle rebored and rechambered. That would retain the on piece quarter rib. I don't think you would have a problem going from .375H&H to .404 J. Usually a reboring specialist will tell you that they need to have some meat in the barrel for the drill to bite into. For instance, you couldn't go from .416 to .404 because there isn't enough to remove and the bit would chatter and wander as it went down the bore.The only issue I can think of is that I believe Ruger barrels are really tough steel due to the hammer forging process. I have seen disclaimers on websites saying that it is possible that the reboring process isn't successful due to the hardness of the metal. The company would be able to talk you through it.


geoff rath

AH enthusiast
Joined
Apr 4, 2017
Messages
405
Reaction score
330
Dave, may I add my prayers for resolution of those medical issues, and good luck with the rechamber job. Changing from 416 Rigby to 404 Jeffery (did I spell it correctly?) is a no-no. the body of the Rigby is quite a bit larger than that of the 404.; the back end of the barrel would need to be removed; a real waste. try to step up from 375 H&H to 404; mucho bettero. Sierraone; I still owe you beers, or something; gotta make the 2019 AH dinner . . .;););)


ActionBob

AH legend
Joined
Dec 12, 2011
Messages
3,810
Reaction score
6,126
Location
Central Minnesota
Media
96
Hunting reports
Africa
4
Mex/S.Amer
1
Member of
NRA life, DSC, SCI
Hunted
Minnesota, Texas, South Africa, Zimbabwe, Mozambique, British Columbia, Argentina, Kansas, Macedonia, Austria

BC.Pat

AH enthusiast
Joined
Mar 28, 2017
Messages
433
Reaction score
447
Location
Victoria, British Columbia
Media
9
Hunting reports
USA/Canada
1
Hunted
Botswana , Namibia, Sierra Leone
I rechambered to 450 rigby from 416 rigby, I used a krieger barrel and my ginsmith machined a new quarter rib for the new barrel, so I could switch back to 416 R if i wanted to.
The gunsmith said the most involved part was the manufacturing of the rib to perfectly match the action.

Pat


ActionBob

AH legend
Joined
Dec 12, 2011
Messages
3,810
Reaction score
6,126
Location
Central Minnesota
Media
96
Hunting reports
Africa
4
Mex/S.Amer
1
Member of
NRA life, DSC, SCI
Hunted
Minnesota, Texas, South Africa, Zimbabwe, Mozambique, British Columbia, Argentina, Kansas, Macedonia, Austria
Anyone know where to get an expanded floor plate for a RSM?

I have the one chambered in 505 Gibbs and it only holds 2, would be great to stuff three in the box.


Rick Cox

AH elite
Joined
Dec 17, 2015
Messages
1,155
Reaction score
1,481
Location
Armstrong British Colombia
Media
102
Articles
1
Hunting reports
Africa
4
USA/Canada
3
Member of
Armstrong Fish and Game Club
Hunted
Namibia, South Africa, British Colombia Ca.
Details on converting the RSM .375 to .404 J ? Contact AZDave, although he is having some family medical issues I believe. He had the rifle re-barreled by PacNor. I ended up buying the rifle, had my smith make some changes to meet my preferences and now have a gorgeous high end rifle which is more accurate than I am, and will be used on buffalo this July. Can't really help you with M 70 or CZ conversions to .404 JView attachment 213439

but I believe the M 70 .375 HH action is too short for a .404, where the RSM action is not. There are several other rifle actions that can be converted with other forum members knowledgeable about how to do so! Good Luck!
Nice rifle and man I love to see groups like that!


sierraone

Silver supporter
AH legend
Joined
Oct 14, 2013
Messages
3,742
Reaction score
3,502
Media
91
Articles
1
Hunting reports
Africa
2
Member of
Dallas Safari Club, Safari Club Int.
Hunted
USA, RSA, Northwest and Limpopo Provinces
Nice rifle and man I love to see groups like that!
Yea, I'm convinced that if I get my chance at the Buff cow in July and she doesn't go down pretty fast, if will definitely be me and not the rifle!


geoff rath

AH enthusiast
Joined
Apr 4, 2017
Messages
405
Reaction score
330
Sierraone, may I ask which bullets you'll be using? Good hunting . . .


sierraone

Silver supporter
AH legend
Joined
Oct 14, 2013
Messages
3,742
Reaction score
3,502
Media
91
Articles
1
Hunting reports
Africa
2
Member of
Dallas Safari Club, Safari Club Int.
Hunted
USA, RSA, Northwest and Limpopo Provinces
Sierraone, may I ask which bullets you'll be using? Good hunting . . .
Bullets....400 gr Barnes TSX, other load data from my son, (I don't reload)
powder...72 gr IMR 4064
Primer...CCI 250
COL...3.50 in
Hornady Brass
2150 FPS
Nosler factory 400 gr solid ammo shoots virtually the same except at 2300-2350 FPS
