9.3x62mm Mauser Rear Sight

Discussion in 'Gunsmithing' started by WebleyGreene455, Dec 3, 2019.

  1. WebleyGreene455

    WebleyGreene455 AH Member

    Joined:
    Sep 21, 2019
    Messages:
    41
    Likes Received:
    17
    Hi everyone.

    I'm wanting to start working on a 9.3x62mm Mauser as a sort of medium-long-term project. I want to use a Kar98k/military-style tangent rear sight on this rifle, but I can't find one and don't really know where else to look. Obviously a sight designed for 8mm Mauser won't work with a 9.3mm, so I can't just put an Kar98k sight assembly on the rifle.

    Does anyone know of someplace I could find such a sight assembly, or someone who could produce or modify one or otherwise help me with this project?

    Thanks,
    W.G.455


  2. Wyatt Smith

    Wyatt Smith AH Enthusiast

    Joined:
    May 9, 2019
    Messages:
    406
    Video/Photo:
    4
    Likes Received:
    390
    Location:
    Pike county
    Would a 7x57 sight calibrated for the round nose 173 grain be close enough. A guy could compare ballistic coefficients and get pretty close.


  3. WebleyGreene455

    WebleyGreene455 AH Member

    Joined:
    Sep 21, 2019
    Messages:
    41
    Likes Received:
    17
    Most 9.3mm I've seen has a much heavier bullet and I was planning to use 258, 286 grain bullets in mine. I'm not sure that a 7x57 sight would work very well with that.


  4. Scrumbag

    Scrumbag AH Fanatic

    Joined:
    Jul 13, 2016
    Messages:
    524
    Video/Photo:
    19
    Likes Received:
    255
    Member of:
    BASC, SCI
    Hunted:
    Europe
    Owning a 9.3x62 I'm wondering how far you are planning on shooting with it? It is not a great long range round and surely you aren't going to hunt with it much more than 200 yds?

    Scrummy


  5. WAB

    WAB AH Elite

    Joined:
    Oct 8, 2015
    Messages:
    1,317
    Video/Photo:
    66
    Likes Received:
    2,145
    Location:
    Alabama
    Member of:
    DSC, NRA, SCI
    Hunted:
    Zambia, Botswana, Mozambique, South Africa, Zimbabwe, Namibia, Scotland, England, Canada, Alaska, Ireland
    The 175 gr 7x57 should be very close in trajectory to the 286 gr 9.3x62. I shoot both of those loads extensively. The BC’s are very close. If I remember correctly the trajectories of my reloads are as follows:

    9.3x62: +3”@100, +0.8”@200, -9”@300
    7x57: +3”@100, 0.0”@200, -12”@300

    I would think irons calibrated to the 7x57 load would be fine out to 250 on the 9.3x62.

    I consider both of these 300yd loads with a little Kentucky windage. I hit a jackal running straight away from me at +300 off the sticks this summer with the 9.3. Just the depth of his body over the spine and thump.


  6. WebleyGreene455

    WebleyGreene455 AH Member

    Joined:
    Sep 21, 2019
    Messages:
    41
    Likes Received:
    17
    I'm thinking about it in meters instead of yards, since I'm sitting here looking at my Kar98k, which has notches in 50m increments up to 1km. Obviously that's vastly out of range for a 9.3mm, but even with, say, 300 or 400m maximum, a 25-meter-increment tangent sight would be fine with me. I've seen those, or similar ones, on vintage rifles before, which is why I've been thinking about one for myself.


  7. Hogpatrol

    Hogpatrol AH ENABLER SILVER SUPPORTER AH Legend

    Joined:
    Apr 13, 2013
    Messages:
    4,210
    Video/Photo:
    52
    Likes Received:
    8,047
    Location:
    Delaware, USA
    Member of:
    Atglen Sportsmen's Club, NRA ,SCCFSA, Bridgeville Rifle & Pistol Club
    Hunted:
    RSA, DE, NJ, PA, KS, TX, ME
    Check the Mauser forums and their classified ad boards.


  8. sgt_zim

    sgt_zim AH Elite

    Joined:
    Mar 26, 2017
    Messages:
    1,047
    Video/Photo:
    13
    Likes Received:
    1,159
    Location:
    Sugar Land, Texas
    Member of:
    NRA, Houston Safari Club Foundation, NWTF
    Hunted:
    Texas, Louisiana
    what @WAB said.

    If the BC is the same, and the MV is the same, two different bullets fired from two different caliber rifles will have a nearly identical ballistic arc.

    I get almost the same trajectory out of 180 gr .308 (BC of about .5) as I get out of 250 gr NAB fired out of my 9.3x62. The 308 is about 75 fps faster at the muzzle. Doesn't matter if you use metric or imperial, the arc is the arc. Set your zero at about 180 meters, and you'll be good to go (without much Kentucky windage) out to about 270 meters.

    bruce moulds and WAB like this.

  9. Mr. Zorg

    Mr. Zorg AH Veteran

    Joined:
    Jun 22, 2019
    Messages:
    203
    Video/Photo:
    2
    Likes Received:
    136
    Location:
    San Antonio, TX
    Have you tried eBay, Gunbroker.com, Armslist.com, Numrich? I teally think eBay and Gunbroker.com are probably the best places to look.

    There might be enough parts on Numrich to individually purchase to assemble one, I didn't look in detail.

    https://www.gunpartscorp.com/gun-manufacturer/mauser/rifles-mauser/1895-span-shrfl-2nd

    If it was my 9.3X62mm rifle, and my eyes were like they were at age 18, I'd put a 3 folding leaf rear sight from Sarco on the barrel.

    https://www.sarcoinc.com/mk10-mauser-3-folding-leaves-express-sight/


    Attached Files:

    Last edited by a moderator: Dec 4, 2019

  10. WebleyGreene455

    WebleyGreene455 AH Member

    Joined:
    Sep 21, 2019
    Messages:
    41
    Likes Received:
    17
    I've looked at Numrich and several other sources for parts. If I decide to go with a 7x57mm rear sight, I should be all set. But I don't really need, or particularly want, one of those. If I could find a sporting tangent sight like I've seen on some vintage rifles, that'd be better, or if an existing sight could be modified, the ramp shaved and the ladder renumbered or something like that I'd be OK with a 7x57 one, but I doubt it would really be worth it in the end.

    I'd originally planned to put three-leaf NECG sights on it and I'd probably be better off with those, save the military tangent for a 7mm or 8mm companion rifle.


  11. Shootist43

    Shootist43 AH ENABLER GOLD SUPPORTER AH Legend

    Joined:
    Apr 25, 2015
    Messages:
    4,611
    Video/Photo:
    22
    Likes Received:
    3,711
    Location:
    Grosse Ile, Michigan
    Member of:
    NRA
    Hunted:
    Michigan, Texas, Missouri, Limpopo Province South Africa
    Take a look at the aperture sight Von Gruff made for one of his Mausers. You may be able to do something similar.

    Von Gruff can you supply a photo so we don't have to go looking?


  12. WebleyGreene455

    WebleyGreene455 AH Member

    Joined:
    Sep 21, 2019
    Messages:
    41
    Likes Received:
    17
    I hadn't given much thought to an aperture, but as long it wasn't in the way of the scope I think I'd be open to the idea.


  13. sgt_zim

    sgt_zim AH Elite

    Joined:
    Mar 26, 2017
    Messages:
    1,047
    Video/Photo:
    13
    Likes Received:
    1,159
    Location:
    Sugar Land, Texas
    Member of:
    NRA, Houston Safari Club Foundation, NWTF
    Hunted:
    Texas, Louisiana
    I think you're going to need to choose one or the other - glass or tangent/aperture, unless you can mount the tangent on the tang.

    Here's a 5-shot group from 100 yards with a NECG aperture mounted on my Zastava Mauser. I'd be more than comfortable shooting out to 250 with this set up.
    hornady 286with NECG.jpg

    WAB likes this.

  14. WebleyGreene455

    WebleyGreene455 AH Member

    Joined:
    Sep 21, 2019
    Messages:
    41
    Likes Received:
    17
    When I say "tangent", I mean a military-style ramp/tangent/ladder sight fitted to the barrel. That or express sights would work fine with a scope. But agreed, an aperture sight would probably get in the way of the scope unless it was attached to the hammer or if it folded and the scope was mounted high enough.

    sgt_zim likes this.

  15. WebleyGreene455

    WebleyGreene455 AH Member

    Joined:
    Sep 21, 2019
    Messages:
    41
    Likes Received:
    17
    Aha! I have discovered McLaughlin's Rigby-style bolt-mounted peep/aperture sights after finding a thread on here and I like the look of those very much indeed. But I feel like I'd be apprehensive about securing a sight to a Mauser bolt (specifically to the hammer). Seems like a problem waiting to happen compared to a receiver- or barrel-mounted sight. Can anyone weigh in on the McLaughlin or Rigby-style in general?

    Here's the thread: https://www.africahunting.com/threads/aperture-sight-difficuties.41044/

    And here's a link to the McLaughlin site: https://mclaughlincustomfirearms.com/rigby-peep-sights/

    @Shootist43 Was that the @Von Gruff rifle you were talking about?


  16. Shootist43

    Shootist43 AH ENABLER GOLD SUPPORTER AH Legend

    Joined:
    Apr 25, 2015
    Messages:
    4,611
    Video/Photo:
    22
    Likes Received:
    3,711
    Location:
    Grosse Ile, Michigan
    Member of:
    NRA
    Hunted:
    Michigan, Texas, Missouri, Limpopo Province South Africa

  17. WAB

    WAB AH Elite

    Joined:
    Oct 8, 2015
    Messages:
    1,317
    Video/Photo:
    66
    Likes Received:
    2,145
    Location:
    Alabama
    Member of:
    DSC, NRA, SCI
    Hunted:
    Zambia, Botswana, Mozambique, South Africa, Zimbabwe, Namibia, Scotland, England, Canada, Alaska, Ireland
    Very cool sighting system Von Gruff!


  18. AZDAVE

    AZDAVE AH Elite

    Joined:
    Jul 26, 2013
    Messages:
    1,388
    Video/Photo:
    132
    Likes Received:
    1,591
    Hunted:
    South Africa, Alaska,lower 48
    The tangent sights on the military rifles were designed as a battle rifle sight, you need to look at the military order of battle and manual of arms for their intended use. The tactics used by soldiers to employ the rifles in warfare vs hunting game with them. The 7x57 and 9.3x62 have about the same trajectory from 50-1000 meters. Out to 300 on game is doable very easily in the hands of a competent riflemen. We have a responsibility to make ethical shots on game to cleanly harvest our game. In warfare you are trying to punch holes in the enemy combatant, and wounding them requires much more logistics (Manpower to evac to medical facilities, care of the wounded vs recovering a dead enemy) so two very different requirements.

    You should be able to use the Tangent sights for your 9.3 and there is a good deal of satisfaction in ringing steel at 500+ with iron sights.


  19. WebleyGreene455

    WebleyGreene455 AH Member

    Joined:
    Sep 21, 2019
    Messages:
    41
    Likes Received:
    17
    Steel and paper are the main reason I'd want the tangent sight. I do like the Rigby-style aperture, though, now I've seen it, so it'll come down between one or the other.


  20. Shootist43

    Shootist43 AH ENABLER GOLD SUPPORTER AH Legend

    Joined:
    Apr 25, 2015
    Messages:
    4,611
    Video/Photo:
    22
    Likes Received:
    3,711
    Location:
    Grosse Ile, Michigan
    Member of:
    NRA
    Hunted:
    Michigan, Texas, Missouri, Limpopo Province South Africa
    Sorry for the late reply. Yes that is the sight on Von Gruff's rifle that I was referring to. For my money the Rigby Aperture would be the way to go.
